InteliNano AMF 5

Order code: IN2AMF5XBAA, IN2AMF5XBAANP, IN2AMF5XBAANU

InteliNano AMF 5 is a smart control solution for small to medium-sized power backup and standby gen-set applications. This controller has Automatic Mains Failure (AMF) and Manual and Remote Start (MRS) features that ensure reliable and efficient performance. It provides complete protection for your gen-set and it is compact, making it easy to install and operate. Moreover, it is compatible with a long list of Engine Control Unit (ECU) options and supports Stage V & Tier4Final, providing more flexibility.

*Please note that the sales order under the product code IN2AMF5XBAANP is for a box with 60 pieces of units.
** The controllers ordered under the IN2AMF5XBAANU order code are not UL 1008 certified.


The InteliNano AMF 5 was announced in February 2024, and is coming soon on the market. Contact us for more information about the date of availability for this product.

  • Easy configuration with InteliConfig
  • Plug-in module slot for remote monitoring
  • Cyber security by design
  • Full 3-phase measurement
  • 5V output reference for analogue inputs
  • E-Stop

InteliNano AMF 5 Datasheet

English (26 Mar 2024)

InteliNano CE EU Declaration of Conformity

English (24 Apr 2024)

Show resource hub for this product
  • Overview
  • Related products
  • Overview
  • Related products
    • InteliNano AMF 5
    Overview
    Related products
InteliNano AMF 5 is an easily configurable unit that provides flexible control of single gen-sets for prime power and stand-by applications. It comes with connectivity and communication features, enabling you to monitor your sites remotely.

The InteliNano AMF 5 offers:

  • Flexible and efficient setup and monitoring using InteliConfig, ComAp’s PC configuration and monitoring tool
  • Precise current measurement in all phases
  • One slot for plug-in modules for 4G-GPS, Ethernet, RS232/485
  • AirGate 2.0 for easy connection to your equipment remotely without worrying about your asset’s IP address
  • Geo-fencing feature with optional 4G-GPS plug-in module helping with efficient unit tracking and theft prevention
  • Remote monitoring of your gen-set operations from anywhere, anytime with WebSupervisor, our cloud-based fleet management tool
  • High-level security features keeping your business and data as safe as possible
  • Secure user access management
  • Integrated communication and control ports on board (USB-C, CAN)
  • User-defined protections and setpoints on top of default protection
  • Event-based history with 100 records for fast and easy troubleshooting
  • Stand-by and prime power application control from one unit
  • Improved hardware platform with switchable analogue input and 5V reference output for analogue sensors
  • Precise measuring with a True Root Mean Square measurement feature
  • Low power mode to avoid battery drainage for prime power applications
  • Possibility to integrate InteliSCADA, our intuitive software tool for quick and simple creation and monitoring of complex SCADA systems
  • Multi-purpose maintenance timer and exercise timers
  • Multi ECU (Electronic Control Unit) with support for two control units
  • Modbus register mapping
  • Power over USB-C for controller configuration
  • Multilingual support and translator option
  • RTC with a replaceable backup battery

Certifications:

  • EN 61000-6-2
  • EN 61000-6-4
  • EN 61010-1
  • EN 60068-2-1 (-20 °C/16 h)
  • EN 60068-2-2 (70 °C/16 h)
  • EN 60068-2-6 (2÷25 Hz / ±1,6 mm; 25÷100 Hz / 4.0 g)
  • EN 60068-2-27 (a=500 m/s2; T=6 ms)
  • EN 60068-2-30:2005 25/55°C, RH 95%, 48hours
  • EN 60529 (front panel IP50, front panel IP65 with gasket, back side IP20)




Please check the manual for a complete list of supported controllers and applications.

Accessories

product img
Gasket IN2
Gasket accessory for InteliNano AMF 5. This optional Gasket IN2 ensures IP65 protection when the controller is panel-mounted.

product img
CM-RS232-485
Communication module enabling integration of genset controller into the local monitoring system over Modbus RTU and a quick connection to ComAp software tools for configuration and monitoring InteliConfig and InteliSCADA.

product img
CM3-Ethernet
An easy-to-use communication solution to help connect gen-set controllers online via wired connection. This plug-in communication module enables remote monitoring and control for the gen-set controllers and provides access to various gen-set values - engine values, generator, load and Mains electrical values - alarms and history from anywhere.

product img
CM2-4G-GPS
An easy-to-use and highly efficient solution for connecting gen-set controllers online via 4G network. Enables remote monitoring and tracking of the gen-set’s exact position, helping to optimise its uptime and reduce maintenance costs.
